Can briquettes crusher

The metal crusher HR-1300 also can crush the metal briquettes(after metal baling press, ≤40kg), bicycle, motorcycle frame, decomposed car shell, etc.
  • Product description
  • Product Parameter

Can packing briquettes crusher

Model:Metal Crusher HR-1300
Mobile/WhatsApp: 008613592505674
http://www.vidacrusher.com
►1.Introduction of Can briquettes crusher HR-1300
     The Can briquettes crusher HR-1300 can not only process the metal scraps that can be processed by metal crusher  HR-600/800/1000, but also can crush the metal briquettes(after metal baling press, ≤40kg), bicycle, motorcycle frame, decomposed car shell, etc. The final products are of small blocks, which are the ideal raw materials for smelting industry.There are hydraulic lid device and forced feeding machine on the metal crusherHR-1300, which is able to prepress the big metal scraps and make it easy enter the breaking chamber.

►2.The application of Can briquettes crusher:
Can briquettes crusher can be widely used in a variety of need to break the scrap metal, car tires, wood, waste paper, plastic, straw, car tires, waste paper, garbage bags and other materials.

►3.working principle:
       Can briquettes crusher The core principle is the use of hammer hit metal materials. Driven by the high-speed high-torque motor, the hammer on the host rotor turns into the cavity to be broken into the cavity, through the liner and the hammer between the formation of space, will be broken to be broken to meet the specifications of broken Material. According to the working conditions of the crusher, can be divided into dry system, wet system and semi-wet system. Dry system mainly refers to the broken material to go through the air swing sorting system, the metal and non-metallic separation, the other system with dust removal device. Wet system refers to the broken water spray at the same time, and in the sorting at the same time to wash the water. Semi-wet system is only in the broken need, a small amount of water, to prevent dust, no cleaning.


►4.Features:
    1. Widely used in the field: In addition to broken scrap metal, but also for wood, waste paper, plastic, straw, car tires, waste paper, garbage bags and other materials such as the collapse of the material.
    2. Easy maintenance: small crusher hobs due to structural size restrictions using the overall structure, medium and large crusher hobs are used to install the structure, can directly replace the damaged hob.
    3. Waste metal crusher equipment Low speed, low noise, high torque, and with mechanical / hydraulic, electrical overload protection.
    4. Waste metal crusher equipment use and maintenance of low cost: equipment design is reasonable, well-made, extending the service life of equipment, reduce equipment use and maintenance costs.

Technical Parameter:

Model PSJ-1300
Power 90KW
Capacity 3000-5000kg/h
Feeding Hole Size 500*1300mm
Discharge Size 18-50mm
Dimension Size 4300*4200*3900mm
N.W. 8.5t
